Explanation
To configure the Trail template in NFM-T for an Uplink board (such as 2UC400) in an MRN network with LO and LI restoration capabilities, you need to check the Logical Link box, set the Port Type to Unterminated, check the ASON Routed box, and uncheck the ASON Tunnel box. This configuration allows you to create a logical link between two Uplink boards that can be used for LO or LI restoration. The logical link is not terminated at the Uplink board, but at the OTU board. The ASON Routed option enables the GMPLS control plane for the logical link, while the ASON Tunnel option is not applicable for Uplink boards. References : Nokia Advanced Optical Network Management with NFM-T Course | Nokia, Nokia 1830 PSS-4, PSS-8, PSS-16 and PSS-32 Platforms – NATO

Explanation
The GMRE node address is the IP address for communication between network elements (NEs) in a GMPLS-controlled optical network. The GMRE node address is also known as the GMRE loopback address or the GMPLS node IP. It is used by GMPLS protocols such as LMP and RSVP to identify and communicate with other GMRE nodes. The GMRE node address is configured on each NE and is advertised by OSPF-TE to other nodes in the same area. References : Nokia 1830 PSS-4, PSS-8, PSS-16 and PSS-32 Platforms – NATO, 1830 PSS Identifiers

Explanation
RSVP-TE Notify message is a message type defined in the RSVP-TE protocol, which is an extension of the RSVP protocol for MPLS traffic engineering. RSVP-TE Notify message is used to inform non-adjacent nodes of LSP events, such as setup, modification, or teardown. This allows the nodes to update their local state information and perform actions based on the notification. For example, a Notify message can be used to trigger a fast reroute mechanism in case of a link or node failure12. References:
* 1: RFC 3473 – Generalized Multi-Protocol Label Switching (GMPLS) Signaling Resource Reservation Protocol-Traffic Engineering (RSVP-TE) Extensions
* 2: RFC 3471 – Generalized Multi-Protocol Label Switching (GMPLS) Signaling Functional Description

Explanation
The Feasibility File is a file that contains a set of target values for various optical impairment parameters, such as OSNR, CD, PMD, and PDL, that are used to determine whether a given LSP can be routed through the GMRE network. The Feasibility File is generated by the Network Planning Application (NPA) based on the network design and the service requirements. The Feasibility File is then loaded into the GMRE nodes and used by the GMPLS routing engine to perform feasibility checks for LSP requests. The Feasibility File ensures that the LSPs are routed in accordance with the network plan and the optical performance criteria12.
References:
* 1: Nokia GMPLS-controlled Optical Networks Course | Nokia
* 2: GMPLS – Nokia

Explanation
GMPLS-enabled nodes use routing protocols, such as OSPF-TE or ISIS-TE, to exchange information about the topology and the state of the links in the network12. This information includes the link attributes, such as bandwidth, wavelength, protection, and shared risk link groups (SRLGs)3. The state of each link indicates whether it is up or down, available or reserved, and so on. This information is used by GMPLS-enabled nodes to compute feasible paths for LSPs and to avoid routing loops or conflicts. The bandwidth and the frequency of each client path are not present in every GMPLS-enabled node, but only in the ingress and egress nodes that initiate and terminate the LSPs. The list of LSPs created in the entire network is also not present in every GMPLS-enabled node, but only in the nodes that are involved in the LSPs or that maintain a global view of the network. References:
* 1: GMPLS – Nokia
* 2: Generalized Multi-Protocol Label Switching – Wikipedia
* 3: Nokia GMPLS-controlled Optical Networks Course | Nokia

Explanation
The SNC state is a parameter that indicates the status of a resource in a GMPLS network. A resource can be a link, a wavelength, a timeslot, or a fiber. The SNC state can have different values, such as N, n, P, p, R, r, and so on. Each value has a specific meaning and implication for the resource and the LSP that uses it. The SNC state of lower case “n” means that the resource is the nominal resource on a TE-link that is notin use. A nominal resource is the default or preferred resource that is assigned to an LSP when it is created. A TE-link is a logical link that represents a set of resources that share the same attributes and constraints. A TE-link can have multiple resources, such as wavelengths or timeslots, but only one of them can be the nominal resource.
If an LSP is using a resource other than the nominal resource on a TE-link, it means that the LSP has been rerouted or switched due to a failure or a constraint violation. In this case, the SNC state of the nominal resource will be “n”, indicating that it is not in use by any LSP12. References:
* 1: Nokia GMPLS-controlled Optical Networks Course | Nokia
* 2: Nokia Network Functions Manager for Transport User Guide | Nokia

Explanation
SFD is not a GMPLS protocol, but a term used in optical networks to refer to the Source Frequency Definition, which is a parameter that specifies the frequency of a wavelength channel4. GMPLS protocols are those that enable the control and management of different types of switching technologies, such as packet, wavelength, fiber, and time-slot switching5. Some examples of GMPLS protocols are OSPF-TE, RSVP-TE, and LMP. OSPF-TE is a routing protocol that advertises the topology and the link attributes of the network6.
RSVP-TE is a signaling protocol that establishes, modifies, and releases LSPs. LMP is a link management protocol that verifies the connectivity and monitors the status of the links. References:
* 4: Source Frequency Definition (SFD) – ITU
* 5: Generalized Multi-Protocol Label Switching – Wikipedia
* 6: OSPF Extensions in Support of Generalized Multi-Protocol Label Switching (GMPLS) – RFC 4203
* [7]: Generalized Multi-Protocol Label Switching (GMPLS) Signaling Resource Reservation Protocol-Traffic Engineering (RSVP-TE) Extensions – RFC 3473
* [8]: Link Management Protocol (LMP) – RFC 4204

Explanation
The Wait for Server Restoration (WSR) parameter in the MRN is a boolean parameter that determines whether an LI service should wait for the LO restoration or not in case of a failure.When WSR is false, the LI services do not wait for the LO restoration and restore through LI switching. This means that if an LO optical channel fails, the LI services that use that channel will switch to another available optical channel at LI layer without waiting for the LO layer to restore the failed channel. This option provides faster restoration time for LI services, but may result in suboptimal resource utilization at LO layer. When WSR is true, the LI services wait for the LO restoration and do not switch at LI layer. This means that if an LO optical channel fails, the LI services that use that channel will remain in that channel until the LO layer restores it or until a timeout occurs.
This option provides optimal resource utilization at LO layer, but may result in longer restoration time for LI services. References : Nokia GMPLS-controlled Optical Networks Course | Nokia, 3. GMPLS – Nokia

Explanation
GMPLS stands for Generalized Multi-Protocol Label Switching, which is a protocol suite that extends MPLS to control different types of switching technologies, such as optical, TDM, and packet switching1. The meaning of Generalized in GMPLS is that it can be used for traffic types other than data packets, such as wavelengths, time slots, or fibers2. GMPLS can also use implicit labels that are derived from the physical properties of the data stream, such as wavelength or timeslot, instead of explicit labels that are carried in the packet header3. This allows GMPLS to support various transport networks and applications, such as optical transport networks (OTN), wavelength switched optical networks (WSON), and automatic switched optical networks (ASON)4. References:
* 1: Nokia GMPLS-controlled Optical Networks Course | Nokia
* 2: What is MPLS and GMPLS? – Metaswitch
* 3: Generalized Multi-Protocol Label Switching – Wikipedia
* 4: GMPLS – Nokia

Explanation
The 3R resource is a type of optical regeneration resource that can be used to extend the reach of optical signals in a GMPLS-controlled optical network. The 3R resource performs three functions: reshaping, retiming, and reamplifying the optical signal. The 3R resource can be added to the Network Planning Application (NPA) in the Nokia Network Functions Manager for Transport (NFM-T) through the Constraint Wizard. The Constraint Wizard is a tool that allows the user to define various constraints and parameters for the network design, such as optical impairments, wavelength availability, protection schemes, and regeneration resources. The user can select the 3R resource from the list of available resources and specify its location, capacity, and cost. The NPA then uses this information to perform feasibility checks and path computation for the LSP requests12. References:
* 1: Nokia GMPLS-controlled Optical Networks Course | Nokia
* 2: Nokia Network Functions Manager for Transport User Guide | Nokia

Explanation
A network with ROADM GMPLS nodes and optical transponder connections could have both L0 and L1 restoration capabilities. L0 restoration refers to the ability of the network to recover from failures at the optical layer, such as fiber cuts or node failures, by rerouting the affected LSPs to alternative paths at the same layer.
L0 restoration can be achieved by using GMPLS signaling protocols, such as RSVP-TE or CR-LDP, to establish backup LSPs in advance or on demand. L0 restoration can provide fast recovery times and high availability for optical services34. L1 restoration refers to the ability of the network to recover from failures at the sub-wavelength layer, such as transponder failures or wavelength unavailability, by rerouting the affected LSPs to alternative paths at a higher layer. L1 restoration can be achieved by using GMPLS routing protocols, such as OSPF-TE or ISIS-TE, to advertise the sub-wavelength information and availability to other nodes in the network. L1 restoration can provide more flexibility and efficiency for sub-wavelength services56.
References:
* 3: GMPLS – Nokia
* 4: Generalized Multi-Protocol Label Switching – Wikipedia
* 5: Sub-Wavelength Switching – Nokia
* 6: Sub-Wavelength Switching in Optical Networks – IEEE Xplore

Explanation
In a 1830PSS MRN network, groups of links can be combined (bundled) together in a single TE-Link both within layer 0 and 1 networks. A TE-Link is a logical representation of one or more physical links that share the same attributes and can be used to establish Label Switched Paths (LSPs). A TE-Link can be either single-layer or multi-layer, depending on the switching capabilities of the links. In a single-layer TE-Link, all the links belong to the same layer, either layer 0 (optical) or layer 1 (OTN). In a multi-layer TE-Link, the links belong to different layers, such as layer 0 and layer 1. A TE-Link can be either bundled or unbundled, depending on the number of links it contains. A bundled TE-Link contains more than one link, while an unbundled TE-Link contains only one link. A bundled TE-Link can provide more bandwidth and flexibility than an unbundled TE-Link. References : Nokia GMPLS-controlled Optical Networks Course | Nokia, 3.
GMPLS – Nokia

Explanation
The Shutting Down state is a transient state that occurs when a TE-link is set to maintenance mode in the NFM-T. In this state, the TE-link is not available for routing new LSPs, but the existing LSPs (SNCs) that use the TE-link are not immediately terminated. Instead, they are soft-rerouted, which means that they are gracefully switched to alternative paths without disrupting the traffic. The Shutting Down state lasts until all the SNCs on the TE-link are successfully soft-rerouted or forcefully terminated. After that, the TE-link transitions to the Administrative Maintenance state, where no traffic can be routed over the TE-link12.
References:
* 1: Nokia GMPLS-controlled Optical Networks Course | Nokia
* 2: Nokia Network Functions Manager for Transport User Guide | Nokia

Explanation
Preemption is a mechanism that allows a higher priority LSP to tear down an existing lower priority LSP in order to obtain the required resources for its establishment. Preemption can occur when there is not enough bandwidth or other resources available on a link or node to accommodate a new LSP request. In this case, the node can select one or more lower priority LSPs that are using the resources and send them a PathErr message with a Preempt error code. This causes the lower priority LSPs to beterminated and release their resources. The node can then allocate the resources to the higher priority LSP and send a Resv message to confirm its reservation34. References:
* 3: RFC 4829: Label Switched Path (LSP) Preemption Policies for MPLS Traffic Engineering4
* 4: MPLS Applications User Guide | Juniper Networks5

Explanation
The SNC Nominal Route is the default or preferred route that is assigned to an LSP when it is created. The SNC Nominal Route is determined by the constraints that are specified by the user during the LSP creation process, such as cost, SRLG, color, bandwidth, protection, and regeneration. The user can modify the SNC Nominal Route in NFM-T by using the Constraint Wizard, which is a tool that allows the user to change the constraints for an existing LSP. The Constraint Wizard will then compute a new SNC Nominal Route based on the modified constraints and update the LSP accordingly34. References:
* 3: Nokia GMPLS-controlled Optical Networks Course | Nokia
* 4: Nokia Network Functions Manager for Transport User Guide | Nokia
